Signal SDS Series User Manual

SDS Series
7
Description
• SDS-50: 48 Station/48 Valve capacity. Activates up to 4 valves
• SDS-100: 98 Station/98 Valve capacity. Activates up to 8 valves
• Operates up to four valves at once, plus master valve/pump, plus auxiliary
• DataCoil™ is a combined solenoid coil and two-wire decoder. Connects directly
to the two-wire cable.
• SDS Series can operate conventional (multiwire) solenoids using RelayCubes.
This can be done in conjunction with two-wire DataCoils when required.
RelayCube 1: Outputs 01—24
RelayCube 2: Outputs 25—48
RelayCube 3: Outputs 49—72
RelayCube 4: Outputs 73—98
CONTROLLER DESCRIPTION — FEATURES:

Signal SDS Series Specifications

General

Type	Surge Protective Device
Maximum Continuous Operating Voltage (Uc)	150V
Short Circuit Current Rating (SCCR)	200kA
Operating Temperature	-40°C to +80°C
Operating Temperature Range	-40°C to +80°C
