Settings
29 / 60
Parameter Values Default value
«0/4mA...20 mA» 0-20 mA/ 4-20 mA 4-20 mA
Set current range for measured value output.
«For service» 0 value/ Last value Last value
Set the measured value output in service mode.
«Max. value» 20 ... 21 mA 21 mA
Set the highest possible current value at the measured value output. Current values above 20.0 mA correspond
to more than 100% measured value of the current measuring range.
«If fault» 0 ... 4mA 2mA
Set the current value to be output in the event of a fault (only relevant for current range 4 ... 20 mA).
Current output 1 ... n
Parameter Values Default value
«Source n» C1...C4/ Math 1...2/ Humidity/ Inac-
tive
C1 (Turb90)
List of available sources. To reduce current consumption, set current outputs that are not needed to Inactive.
«Measuring range n» -5000 ... 1E9 0 ... 1000
Set the from ... to values of the measuring range.
9.3.1.2 Communication module EG_PoE
Only available with communication module EG_PoE.
Parameter Values Default value
«DHCP» On/ Off On
Automatic assignment of IP addresses.
l
DHCP On: Assigned IP address, gateway address and subnet mask are displayed.
l
DHCP Off: Enter IP address, gateway addr., sub-net mask and DNS server manually.
«IP address» XXX.XXX.XXX.XXX 192.254.1.1
Enter IP address.
«Gateway addr.» XXX.XXX.XXX.XXX 192.255.255.0
Enter gateway address.
«Sub-net mask» XXX.XXX.XXX.XXX 255.255.255.0
Enter subnet mask.
«DNS server» XXX.XXX.XXX.XXX 0.0.0.0
Enter DNS server address. Appears if DHCP is set to Off.
9.3.1.3 Communication Module EG_Profinet
Only available with communication module EG_Profinet.
