SIGRIST TurBiScat PM 40 User Manual

Settings
33 / 60
9.4 Advanced configuration mode
If necessary, change the configuration mode.
9.4.1 Menu: IO module EG_IO
Only available with communication module EG_IO.
IO Configuration\ General
Parameter Values Default value
«0/4mA...20 mA» 0-20 mA/ 4-20 mA 4-20 mA
Set current range for measured value output.
«For service» 0 value/ Last value Last value
Set the measured value output in service mode.
«Max. value» 20 ... 21 mA 21 mA
Set the highest possible current value at the measured value output. Current values above 20.0 mA correspond
to more than 100% measured value of the current measuring range.
«If fault» 0 ... 4mA 2mA
Set the current value to be output in the event of a fault (only relevant for current range 4 ... 20 mA).
«Name ext. in.» ... External
Assign a designation to an external input signal (maximum 7 characters).
«Prio. ext. in.» Off/ Warning/ Fault/
Prio fault
Warning
Assign a priority to the external input signal.
IO configuration\ IO 1 ... 6
The assigned functions vary depending on the selection of IO 1 ... 6
Function IO 1 IO 2 IO 3 IO 4 IO 5 IO 6
Modbus RTU 120 Ω RS485 A RS485 B
Modbus RTU RS485 A RS485 B
Digital input
(5-28V)
x x
Digital output (high-
side switch - max. 20
mA)
x x x x
Current output (max.
700 Ω)
x x x x
Parameter Values Default value
«Function» 1) Off/ Modbus RTU 120 Ω/ Modbus
RTU/ Digital input/ Digital output/
Current output
Off
Parameters are assigned to the functions and can be configured as required.
1)
The Off function disables the function.
l Modbus RTU with 120 Ω (with terminating resistor)
l Modbus RTU (without terminating resistor)
