Settings
35 / 60
Parameter Values Default value
«Measuring range» 0 ... 4000 0 ... 1000
From ... To values of the measuring range.
Digital output\ limit value (IO 1 ... 4)
This function only appears if the limit value has been activated in the "Digital output" function.
Parameter Values Default value
«Source» C1 ... Cn/ M1 ... Mn/ Humidity C1 Turb90
Available sources.
«Mode» Inactive/ Exceed./ Undershoot. Inactive
Set whether the limit value function is inactive or should react to undercutting or exceeding the limit value.
«Upper limit» 0 ... 999999 1,000
Set upper limit value.
«Lower limit» 0 ... 999999 0,900
Set lower limit value.
«Cut in delay» 0 ... 60000 0 s
Enter the cut-in delay for the respective limit value channel.
«Cut-out delay» 0 ... 60000 0 s
Enter the cut-out delay for the respective limit value channel.
9.4.2 Menu: IO module EG_PoE
See communication module EG_PoE [}29]
9.4.3 Menu: IO module EG_Profibus
See communication module EG_Profibus [}30]
9.4.4 Menu: IO module EG_Profinet
See communication module EG_Profinet [}30]
9.4.5 Menu: WLAN
WLAN\ General
Parameter Values Default value
«WLAN region» List of regions USA
Select the region in which the device is operated. In the USA, WLAN channels 1 ... 11 are used. In the other
countries, channels 1 ... 13 are used.
WLAN\ base station
Parameter Values Default value
«MAC address» F0:26:4C:XX:XX:XX Device-specific
Displays the MAC address of the WLAN access point.
