Settings
37 / 60
9.4.7 Menu: Display
Display\ General
Parameter Values Default value
«Values» Min. value/ Max. value/ Mean value Mean value
Selection of the measuring value display in the graphic display.
«For service» 0 value/ Last value Last value
Value displayed in the graphic display during service operation.
«Image rotation» 0°/ 90°/ 180°/ 270° 0°
Set the orientation of the display on the photometer.
«Display brightness» 0 ... 100% 60%
Set the brightness of the display on the photometer.
NOTICE!
Low brightness reduces power consumption and extends the life of the display.
«Power-saving mode» 0 ... 65535 s 300 s
Time period after which the display brightness on the photometer is reduced without manipulation.
«Standard display» Values/ 1 hour/ 1 day/ 7 days/ Sen-
sor status
Values
If «Show Idle Icon» is disabled, the display will change to the standard display after 3 minutes of inactivity.
Display\ channel D1 ... Dn
Parameter Values Default value
«Source» C1 ... Cn/ M1 ... Mn/ Humidity/ Inac-
tive
Cn
Sequence of the measuring channels as they are to be shown in the display. The source refers to the channels
defined in the «Meas. Channels» menus.
«Resolution» 1/ 1.2/ 1.23/ 1.234 1.234
Set the number of decimal places after the decimal point to be used for displaying measured values.
«Min. Auto» Off/ On Off
Activate automatic scaling of the graphic display to the minimum value.
«Min. value» 0 ... 999999 0,000
Set the minimum value of the graphic display when automatic scaling is switched off.
«Max. Auto» Off/ On On
Activate automatic scaling of the graphic display to the minimum value.
«Max. value» 0 ... 999999 1,000
Set the maximum value of the graphic display when automatic scaling is switched off.
