Settings
28 / 60
9.3 Simple configuration mode
If necessary, change the configuration mode.
9.3.1 Menu: Configuration
Parameter Values Default value
«WLAN region» List of regions USA
Select the region in which the device is operated. In the USA, WLAN channels 1 ... 11 are used. In the other
countries, channels 1 ... 13 are used.
«System time» Adjust...
Apply the date and time.
«Image rotation» 0°, 90°, 180°, 270° 0°
Orientation of the display.
«Access code» ... 0
Enter access code (numbers only). Used to protect against unauthorised access.
«Designation» ...
Enter the name of the measurement point identification in the Sigrist-Webinterface (max. 13 characters).
9.3.1.1 Communication module EG_IO
Only available with communication module EG_IO.
Parameter Values Default value
«Function» Connection to SICON/SiDis
0/4..20 mA output
*) Customer-specific
Select configuration templates:
Connection to SICON/SiDis: IO 1: RS485 A/ IO 2: RS485 B/ IO 3 ... 6 Inactive
0/4..20mA outputs_ [}29]: IO 1: Digital output - Warning, Error, prioritised/ IO 2: Digital output - Inactive/ IO 3:
Current output channel 1/ IO 4: Current output channel 2/ IO 5: Current output channel 3/ IO 6: Current output
channel 4
*)
Further settings can be made in the advanced configuration mode [}33].
Connection to SICON/ SiDis
Parameter Values Default value
«Integration» 0 ... 60000 s 10
Set the integration time for all measuring channels.
All other parameters can be set on the SICON/SiDis or mobile device.
0/4..20 mA outputs
Parameter Values Default value
«Integration» 0 ... 60000 s 10
Set the integration time for all measuring channels.
