2.2 EtherHaul Package Content
An EtherHaul link consists of two ODUs and two mounting assemblies.
The EtherHaul packages include the following components:
Package
Description
Quantity
EtherHaul ODU
EtherHaul ODU (integrated
antenna)
1
Connecting cable All-
Weather shells
3
Unit grounding cable (90
cm)
1
Alignment RSSI adapter
cable for DVM
1
EtherHaul
mounting
assembly
EtherHaul mounting
assembly
1
Steel Worm Clamps
2
7mm Hex Bolts
4
2.3 Unpacking the EtherHaul
The EtherHaul package content should be examined carefully before installation.
When you unpack the components of the EtherHaul, it is important to use care so as to
avoid damaging or scratching the antenna radome:
 Keep the plastic antenna protective cover while handling the ODU. It protects
the antenna radome.
2.4 Required Tools
Ensure that you have the following tools with you when performing an EtherHaul
installation:
 Standard handheld digital voltage meter (DVM) with probes
 Philips screwdriver, medium size head for grounding connection
 Flat-head screwdriver, medium size (5mm) head for fastening the worm-clamp
that holds the mounting brackets
