Siklu EtherHaul 710 - 2.10 Aligning the Antenna

EH-500/600 Installation Manual
Page 29
The provided protective All-Weather Shells fit cables from 3.5mm to 9.0mm diameter.
1. Thread the cable and tight the shell to the ODU firmly by hand (do not use tools).
2. Insert the rubber gasket snugly and tight the connector lock.
Caution:
To avoid accidental damage to the connector, when removing the All-Weather Shell,
unlock the gland first.
2.9 System LEDs
LED
Color
Description
PWR (Power)
Green – Power OK
Blink Green – Device boot
Red – Power Failure
Off – No Power
RF
Green – Link Up
Blink Green – Device boot
Orange – Alignment Mode
Off – Link Down
ETH1/2/3:
Green – Link 1G
Blink Green – 1G activity
Orange – Link 10/100
Blink Orange – 10/100 activity
Off – No Link (Carrier)
BT/GPS
For future use
2.10 Aligning the Antenna
The ODU antenna must be aligned on both local and remote ODUs. You must first
perform coarse alignment on each ODU, followed by fine alignment. Accurate alignment
of the ODU is critical for achieving the strongest possible receive signal.
The ODU has three modes of operation:
 Alignment – Carrier Wave transmission. Used for antenna alignment.
 Adaptive – Operational mode used with adaptive bandwidth, code, and
modulation.
 Static – Operational mode used with a fixed modulation profile.
ODUs are shipped from the factory in Adaptive mode.
To perform antenna alignment, the ODUs should be in Adaptive mode.
