Functional Description
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 12 of 38
Parameter display
Parameter no.
acc. To chapter 4
Description

16
Display divisor
Selection:
: 1
: 10
: 100
: 1000

23
Sense of rotation
Selection:
: i sense of rotation (cw)
: e sense of rotation (ccw)

26
Calibration value
Value range: -9999 … 9999

Selection:
: no calibration
: Execute calibration now

25
Offset
Value range: -9999 … 9999

27
Target window 1
Value range: 0 - 9999

30
Pos Type
Selection:
: direct
: loop +
: loop -

31
Loop length
Value range: 0 - 9999

28
Target window 2
Value range: 0 - 9999
Table 4: Positioning menu
