Siko AP04 User Manual

Communication via SIKONETZ5
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 34 of 38
Parameter
Name
Access
Format
Description
no.acc. to
chapter 4
Adr.
[hex]
3
0x00
Node address
rw
Unsigned8
Value range 0 … 31
Parameter changes become
active only after cold start
or software reset.
4
0x01
Baud rate
rw
Unsigned8
0 = 19200
1 = 57600
2 = 115200
Parameter changes become
active only after cold start
or software reset.
6
0x02
Bus Timeout
rw
Unsigned16
Value range 0 … 20
(see chapter 8.7.1 Bus
Timeout)
7
0x03
Reply parameter
to write set
point command
rw
Unsigned8
0 = Set point
1 = Actual position
2 = Differential value
9
0x04
Enable keys
time
rw
Unsigned8
Value range 1 … 60
11
0x05
Key function
enable reset
rw
Unsigned8
0 = key function locked
1 = Calibration (reset) key
function enabled
14
0x06
LED blinking
rw
Unsigned8
0 = LED display glows
constantly
1 = LED display blinks
12
0x08
LED 1 red
rw
Unsigned8
0 = LED 1 red Off
1 = LED 1 red On
13
0x09
LED 1 green
rw
Unsigned8
0 = LED 1 green Off
1 = LED 1 green On
15
0x0A
Decimal places
rw
Unsigned8
Value range 0 … 4
0 = 0
1 = 0.0
2 = 0.00
3 = 0.000
4 = 0.0000
16
0x0B
Display divisor
rw
Unsigned8
Value range 0 … 3
0 = 1
1 = 10
2 = 100
3 = 1000
18
0x0C
Direction
indication
function
rw
Unsigned8
Value range 0 … 2
0 = on
1 = inverted
2 = off
19
0x0D
Display
orientation
rw
Unsigned8
0 = normal
1 = rotated by 180°
