MOTHER
BOARDJ9
OPTIC READER
Laser receiver
Laser transmitter
MOTHER BOARD J13
MOTHER BOARD J14
STEP MOTOR Y AXIS
STEP MOTOR X AXIS
red
light blue
green
yellow
red
white/red
green
white/green
MOTHER BOARD J12
X AXIS SENSOR
Y AXIS SENSOR
MOTHER BOARD J15
yellow
black
light blue
brown
black
light blue
brown
light blue
black
