4.3 STOP POSITIONS (KEY STOP)
HEAD STOP
D
C
B
A
0
Fig. 29 - Stop 0
TIP STOP
12
D
C
B
A
Fig. 30 : Stop 1 - 2
Use the bar provided (Ch.4.3) for keys without stops with the tip as a reference.
The choice of position 1 or 2 depends on the length of the cuts.
Insert the bar into the grooves on the clamp.
ATTENTION: remove the bar before proceeding with the cutting operation.
ATTENTION: it is not necessary to apply force to the handle to grip the key in the clamp
properly.
