Silca POKER PRO - Page 36

MOTHER BOARD J10
GAUGE SENSOR
black
yellow
light blue
black
brown
light blue
CUTTER MOTOR +
MICRO CARTER
+ -
M
Cutter
motor
Micro
carter
POWER SUPPLY
+24V
+24V
1
6
1
2
3 red
4 black
5 black
6 black
1
2
red red
black black
+/-
MOTHER BOARD J4
MOTHER BOARD J7
Operating manual POKER PRO
Copyright Silca 2019
32
