Default values shown.
Picture mode – selects if camera shows a colour or monochrome (IR/low light sensitive) image. COL/MON will
automatically select colour or monochrome dependent on image brightness
AE mode – determines if camera image settings are set automatically or biased to manually selected values (set within this
menu).
Shutter – If AE Mode is Manual or Shutter the shutter speed is held to this value.
Iris – If AE Mode is Manual or Iris the Iris position is held to this value.
Backlight comp. – enables the Backlight compensation facility of the camera.
WDR mode – enables the Wide Dynamic range function of the camera.
White balance – sets if the picture colour balance is Automatic of biased to a selected ambient lighting type..
ICR threshold – sets the image/scene brightness level that the camera will automatically change between colour and
monochrome pictures, (if picture mode is COL/MON) .
Digital zoom – enables digital enlargement of the image. This is operated as an extension of the optical zoom function
– beyond the maximum optical telephoto.
Mirror image – enables horizontal reversing of the picture – does not re-orientate PT operation.
Flip Image. – enables vertical reversing of the picture – does not re-orientate PT operation.
Module number – displays the video module's identity code – for factory/servicing use..
Reset (on reboot|) – will cause the video module to be reset when the Oculus is next rebooted. Factory and servicing use
only.
Silent Sentinel Oculus
Version n.nnn (xxxx) xx
SN: FFFFFFFF POST: 000000000
Picture mode COL/MON
AE Mode Auto
Shutter 1/1
Iris F1.6
Backlight comp Off
WDR mode Off
White balance Auto
ICR threshold 28
Digital zoom On
Mirror Image Off
Flip Image On
Module number 1097
Reset (on reboot)
Exit menu
