Configuration.
Orientation sets the installation orientation for the camera. Cameras may be mounted in a Hanging, Upright or upright-Tilted
position. Setting the correct orientation will allow the camera to set the horizon level. This setting requires a re-boot of the
camera to take effect.
Positioning speed controls the rate the camera moves under operator control and when moving to preset positions. The
slowest rate is 1 which is equivalent to 22.5 degrees per second maximum and the fastest rate is 8 which is equivalent to 180
degrees per second maximum. This is the peak rate. Slower rates are available through the zoom dependant speed control
and via the settings for the preset points.
Low voltage PSU allows for use of 12VDC power from battery systems, adjusting power consumption accordingly. (IR lamp
models limited to 13VDC in this mode).
Pan limit left and right set limits for the camera travel. The figures are in degrees and the zero point of the camera needs to
be included in the sweep of the travel (although it can be the left or right limit). When these values are both set to 0 (zero) then
the camera travel is unlimited.
Tilt limit down and tilt limit up can be used to limit the tilt travel range. The zero point needs to be included in the range;
although it can be the top or bottom limit.
Set North sets the current camera pan position to be north. This affects the display of the compass bearing and axis readouts
on the telemetry display.
Wash duration sets the period for the wash cycle. This is in seconds.
Wiper duration sets the period for the wiper cycle. This is in seconds.
Heater function allows you to declare whether the optional temperature control device within the camera housing is a heater or
a cooler. If ‘Heater’ is chosen, the Heater threshold setting below will represent a negative Centigrade value, whereas if the
‘Cooler’ setting is selected, the Heater threshold will represent a positive Centigrade value.
Heater threshold determines the temperature (0 to 40 Centigrade) at which the optional temperature control device within the
camera housing should be activated. The value will either represent a positive or negative Centigrade value depending on
whether the temperature control device is a heater (negative) or a cooler (positive).
Ext-pos functions sets the base preset number for first of the extended functions that are available as presets – Menu preset
override.
Silent Sentinel Oculus
Version n.nnn (xxxx) xx
SN: FFFFFFFF POST: 000000000
Orientation Upright
Positioning speed 4
Low voltage PSU Off
Pan limit left 0
Pan limit right 0
Tilt limit down 0
Tilt limit up 0
Set North Store
Wash duration 15
Wiper duration 7
Heater function Off
Heater threshold 0
Ext-pos functions 2
Exit menu
