Easy Operation Guide

Loading roll paper

Remove the front cover in front of the machine.

Additional information

•

Raise the front of the machine, release the two locks at the bottom of the machine, and remove the

front cover in the direction of the arrows.

•

Please note that the top cover may open forcefully when lifting the front of the machine.

Front cover

Top cover

Arrow

Lock

Arrow
