LED Error Messages
If there is an error status, the LED remains lit until the AC power cord is removed. An LED
message is dened by its blinking sequence. A long blink is dened as 1 second. A short blink is
dened as 0.3 seconds. The LED messages are listed below:
errOr cOde MeSSaGe led flaSh
Environment Over Temperature 1 long blink / 1 short blink
DMD Over Temperature
1 long blink / 2 short blinks
Lamp Over Temperature 1 long blink / 3 short blinks
Fan1 Locked
1 long blink / 4 short blinks
Fan2 Locked
2 long blinks / 2 short blinks
Fan3 Locked
2 long blinks / 3 short blinks
Fan4 Locked 2 long blinks / 4 short blinks
DMD Initial Fail 3 long blinks / 1 short blink
Lamp Initial Fail 3 long blinks / 2 short blinks
Ballast UART Error 3 long blinks / 3 short blinks
Temperature Sensor Fail 3 long blinks / 4 short blinks
Inter Lock Open 4 long blinks / 1 short blink
NOTE
LED displays in blue only.
