3.7.2 Setting parameters
Set the parameters as shown in the table to ensure that the con-
troller recognises the system, on both the MASTER (parameter
140=1) and the SLAVES (parameter 140=2,3).
MASTER:
System identification
–
Setting mode = USER
(refer to section on parameter setting levels
)
–
Setting mode = INSTALLER
(refer to section on parameter setting levels)
N.B.:
In the case of non-condensation boilers, the temperature of return
to the boiler must be raised and care must be taken to prevent pro-
blems related to condensation of flue gases using parameter 22 0EM.
–
Setting mode = MANUFACTURER
(Refer to section on parameter setting levels
)
SLAVE 1:
System identification
–
Setting mode = USER
(refer to section on parameter setting levels
)
–
Setting mode = INSTALLER
(refer to section on parameter setting levels
)
–
Setting mode = MANUFACTURER
(Refer to section on parameter setting levels
)
NOTE:
If there are only two boilers, use the settings for SLAVE
1 only.
SLAVE 2 (applies to third boiler only):
System identification
–
Setting mode = USER
(refer to section on parameter setting levels
–
Setting mode = INSTALLER
(refer to section on parameter setting levels
)
–
Setting mode = MANUFACTURER
(Refer to section on parameter setting levels
)
System identification
ZONE 1: mixer valve, pump, zone probe and room temperature
control unit (refer to RVA46.531 series D manual)
System identification
–
Setting mode = USER
(refer to section on parameter setting levels)
–
Setting mode = INSTALLER
(refer to section on parameter setting levels)
ZONA 2: pump and room unit
(refer to RVA46.531D manual)
System identification
–
Setting mode = USER
(refer to section on parameter setting levels)
–
Setting mode = INSTALLER
(refer to section on parameter setting levels)
Par Description Default values Setup
17 Slope of heating curve 15 –.––
Par Description Default values Setup
17 Slope of heating curve 15 –.––
Par Description Default values Setup
17 Slope of heating curve 15 –.––
Par Description Default values Setup
90 Minimum limitation of boiler temperature 8 40
91* Type of burner 1 0
95 Pump function output Q1 1 6
121 Release of d.h.w. heating 1 2
140 LPB device address 1 1
* For single stage boilers only
Par Description Default values Setup
9 Operating mode of boiler 2 1
22 Minimum limitation of boiler return temp.. 8°C 35°C
44 Prot. against discharging during d.h.w. heating 2 1
Par Description Default values Setup
90 Minimum limitation of boiler temperature 8 40
91* Type of burner 1 0
95 Pump function output Q1 1 6
96 Use sensor input B10/70/B4 0 1
140 LPB device address 1 2
148 Clock mode 3 2
* For single stage boilers only
Par Description Default values Setup
9 Operating mode of boiler 2 1
Par Description Default values Setup
9 Operating mode of boiler 2 1
Par Description Default values Setup
90 Minimum limitation of boiler temperature 8 40
91* Type of burner 1 0
95 Pump function output Q1 1 6
140 LPB device address 1 3
148 Clock mode 3 2
* For single stage boilers only
Par Description Default values Setup
17* Slope of heating curve 15 15
*Depending on the type of system
Par Description Default values Setup
69* Setpoint of d.h.w. temperature 80 70
85 LPB device address 0 4
87 Clock mode 0 2
*Depending on the type of system
Par Description Default values Setup
17* Slope of heating curve 15 15
* Depending on type of system. In pump circuits the room temperature
control unit is required to prevent overheating
