User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
CP2 CP4
Max input frequency
for quad signals* **
5kHz 5kHz
Max input frequency
for other signals **
10kHz 10kHz
Counter capacity 4 503 599 627 370 495 pulses
(52 data bits)
4 503 599 627 370 495 pulses
(52 data bits)
Input current
consumption
about 14mA @24V
about 6mA @10V
about 14mA @24V
about 6mA @10V
Insulation strength
(between individual
measurements inputs)
2kV 2kV
Protection 50mA auto-reset fuse 50mA auto-reset fuse
Isolation strength
(between internal
circuits and
measurements inputs)
1 min. @ 500V AC 1 min. @ 500V AC
Weight 47 g 46 g
*For signals with the frequency greater than 3kHz it is recommended to keep the duty cycle
around 50% and phase shift 90.
**Shift between input signals edges has to be at least 100ms.
Tab. 8.19. Technical data for the CP2 and CP4 modules
294
