User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Fig. 8.20. Internal structure of the optoisolated Universal counters modules
295
Inp11
Inp12
Prg1
Res1
COM 1
COM 2,3,4
R=1.4k
R=1.4k
R=1.4k
R=1.4k
F 50mA
F 50mA
F 50mA
F 50mA
Inp21,31,41
Inp22,32,42
Prg2,3,4
Res2,3,4
Main board
Interface
Isolation
