(e.g. if the maximum number of LockNodes for this RouterNode has
already been reached). These RouterNodes are displayed for complete-
ness only.
7. Click on the OK button.
9 The "Result" window closes.
9 LockNode is assigned to the desired RouterNode.
Reassigning several LockNodes to one RouterNode
ü WaveNet Manager opened via LSM (see
Best Practice: From the LSM
software [}37]
)
ü LockNodes and RouterNodes connected to power supply.
ü LockNodes and RouterNodes connected to WaveNet (test see
Testing
accessibility (WaveNet) [}174]
.
ü LockNodes with currently poor connection known (see
Check signal
quality [}171]
.
1. Right-click on the RouterNode to which you want to reassign
LockNodes.
9 The window "Administration" opens.
WaveNet (Manual)
5. WaveNet Manager
147 / 210
