Comparison voltages (RN and RN2)
<0,9V
DC
LOW (no signal)
>2.1V
DC
HIGH (signal)
Status/responsiveness of the LockNodes
In the area"Status of inputs" you can also see the behaviour of the
LockNodes during the last broadcast:
Error No reply Successful
Processing of the command in
the LockNode of the locking
device faulty.
There are two possibilities
here:
 Locking device with
LockNode did not receive
command and therefore
did not respond.
 Locking device with
LockNode has received
command but RouterNode
has not received response.
The LockNode locking device
has received the command
and the RouterNode has re-
ceived the response.
Status of the outputs
In the area "Status and settings of outputs" you can see the status of the
outputs and can switch outputs manually.
Status of the inputs Meaning
Output Output is switched.
Output Output is not switched.
1. Activate the checkbox Output of the output that you want to switch
or deactivate the checkbox
Output that you no longer want to
switch.
2. Click on the button Set .
9 The "I/O status" window closes.
9 The window "WaveNetManager"opens.
