Exceedance
Shortfall
Time
Voltage
Exceedance threshold
Shortfall treshold
With hysteresis, the same voltage curve triggers exactly one overshoot. The
overshoot is only detected again after the voltage has fallen below the
thresholds.
LockNode
ü WaveNet Manager opened via LSM (see
Best Practice: From the LSM
software [}37]
)
ü LockNodes reachable (see
Testing accessibility (WaveNet) [}174]
).
Right-click on the entry of the LockNode whose IO configuration you
want to change.
9 Window "I/O configuration" opens (window and settings version-
dependent, picture is an example).
9 You can set the IO configuration.
