NOTE
200 mV hysteresis band
The analogue signal applied may be susceptible to interference and fluctu-
ate slightly depending on its nature. If the thresholds were too close to-
gether, even small changes in the voltage would trigger several unintended
events in succession.
The WaveNet Manager automatically sets the threshold value for falling
below the threshold for exceeding by 200 mV (hysteresis). This increases
the operational reliability of the RouterNode.
Voltage
Time
Shortfall/exceedance threshold
Exceedance
Exceedance
Shortfall
Without hysteresis, the same voltage curve will cause the threshold to be
exceeded twice.
WaveNet (Manual)
5. WaveNet Manager
83 / 210
