8 Mower Deck Repair
38” Deck & Arbors
1 4 BEARING
2 2 HOUSING, Arbor, Top
3 2 ADAPTER, Blade
4 2 WASHER, Spring
5 2 WASHER, Spline
6 2 SHIELD, Grass, Upper
7 8 SCREW, Hex, Taptite, 5/16 x 3/4
8 2 COLLAR, Mower Arbor
9 2 ARBOR SHAFT KIT (Incl. Ref. No. 8)
10 2 ARBOR SHAFT ASSY. (Incl. Ref. Nos. 1 & 9)
11 1 MOWER HOUSING ASSY
12 2 SHIELD, Grass, Lower
13 2 WASHER, Shim
14 2 HOUSING ASSY., Arbor, Bottom
(Incl. Ref. Nos. 19 & 26)
15 2 GUIDE, Upstop, Belt
16 1 BLADE, Mower, 22-1/4
17 1 PULLEY ASSY., 4-1/4" O.D., LH
18 1 PULLEY ASSY., 6" O.D., RH
19 2 GREASE FITTING
20 1 BLADE, Mower, 16-1/8
21 1 CLAMP
22 1 SPRING
23 1 PLUG, Hole
24 1 DEFLECTOR, Plastic
25 1 ROD, Deflector, Front
26 2 GASKET, Foam
27 2 NUT, Hex, 1/4-20
28 2 LOCKWASHER, 1/4
29 4 LOCKWASHER, 5/16
30 4 NUT, Hex, 5/16-18
31 2 LOCKWASHER, 7/16
32 1 WASHER, Plain, 5/16
33 4 WASHER, Flat, 5/16
34 2 CAPSCREW, Hex Hd., 7/16-14 x 1
35 4 WASHER, Flat
36 4 SCREW, Hex, Taptite, 5/16 x 1-1/2
37 2 CARRIAGE BOLT, 1/4-20 x 7/8
38 2 WASHER, Plain
39 2 WASHER, Plain
40 1 NUT, Push On
41 2 CAPSCREW, Hex Hd., 7/16-14 x 3-1/4
Ref. Qt. Description Ref. Qt. Description
38" Mower Deck - Deck & Arbors
To Next Page
