8 - 5
8 Mower Deck Repair
38” Clutch & Support
Ref. Qt. Description Ref. Qt. Description
1 1 SPRING
2 2 SPACER
3 1 FITTING, Grease
4 1 SPACER
5 2 BUSHING
6 1 GRIP, Lever
7 1 SPACER
8 1 V-BELT
9 1 GUARD, Belt
10 1 IDLER PULLEY (Incl. Ref. No. 7)
11 1 ROD, Latch
12 1 CLUTCH LEVER ASSY. (Incl. Ref. Nos. 3 & 5)
13 1 HITCH ASSY.
14 1 SPRING
15 1 NUT, Hex, Full, 3/8-16
16 1 LOCKWASHER, 3/8
17 3 NUT, Hex, Lock, 3/8-16
18 2 CAPSCREW, Hex, 3/8-16 x 1-1/2
19 4 WASHER, Plain
20 1 WASHER
21 2 WASHER, Plain, 3/8 I.D.
22 2 CAPSCREW, Hex Hd., 3/8-16 x 2-3/4
23 1 NUT, Hex, Flange, 2-Way Lock, 3/8-16
24 2 NUT, Push On, 3/8
38" Mower Deck - Clutch & Support
