Simplicity LTH Series Service Manual

5 Electrical Troubleshooting
Lower Wiring Harness
5 - 4
**2044
8
3
7
9
2
1
15
11
5
13
4
10, 12
16
14
6
To engine fuel shut-off,
jumper wire (Ref. No. 16) used
on 15HP Briggs & Stratton only
Ground to R.H.
front engine
mounting bolt
To oil pressure
sending unit,
Briggs & Stratton
units only.
To oil pressure
sending unit,
Kohler units only.
Kohler units
only
Electric
Clutch
Briggs & Stratton
units only
Grommet - see Hood,
Grille & Dash Group
Kohler units
only
To Upper
Harness
See Engine
Group
To engine fuel
shut-off, Briggs &
Stratton Vanguard only
(not used on single
cylinder engines).
Location of engine
kill wire on
single cylinder
Briggs & Stratton
models only
Location of
engine kill wire
on twin cylinder
Briggs & Stratton
models only
NOTE: Unless noted otherwise, use the
standard hardware torque specification
chart. See Table of Contents.
Figure 1. Lower Wiring Harness
