5 Electrical Troubleshooting
Lower Wiring Harness
1 1 WIRE ASSY., Headlight
2 2 SOCKET, Bulb
3 2 BULB, Headlight, 12.8V
4 2 TIE, Cable
5 2 BUSHING, Snap, Small
6 1 LENS, Headlight
7 1 BEZEL, Headlight
8 1 HEADLIGHT ASSY. (Incl. Ref. Nos. 2, 3, 6, 7 & 9)
9 2 HEAT SHIELD
10 1 HARNESS ASSY., Lower
(14, 15 & 16 HP Briggs & Stratton)
11 1 WIRE ASSY., Seat Switch
12 1 HARNESS ASSY., Lower (14 & 15 HP Kohler)
13 1 BUSHING, Snap, Large (14 & 15 HP Kohler only)
14 1 WIRE ASSY., Engine Ground
15 1 SWITCH, Seat, Operator Present
16 1 WIRE ASSY., Jumper (15 HP Briggs & Stratton only)
