Simrad AP25 Autopilot
10 20221495F
Other documentation material that is provided with your system
includes a warranty card. This must be filled out by the
authorized dealer that performed the installation and mailed in to
activate the warranty.
1.3 System components
A basic AP25 system consists of the following units (refer to
Figure 1-1):
• AP25 Control Unit with accessories
• Autopilot Computer
• Rate compass
• Rudder Feedback Unit with transmission link
• Drive unit
The basic system can be expanded with multiple fixed and hand
held full function control units, hand held remote and steering
lever.
Figure 1-1 AP25 Basic system
