The display will show the set wind angle. Adjustments to this set
angle can be made by using the course knob or PORT or STBD
button.
The display also presents heading and rudder angle.
Wind (vane) mode
Set wind angle: 044 degrees from stbd.
Measured wind angle: 041°A (apparent)
(T = True)
Course to steer: 309°
Compass reading: 311° M (magnetic)
T (true)
Heading source: Rate compass
Rudder angle: 01° to port
Speed over ground (SOG): 8.0 kts
Parameter: LO-A (Low response,
automatic set)
Steer port Steer stbd.
Adjust set wind angle 1°/push Major wind angle adjust
CCW: Steer port CW: Steer stbd
Regain manual steering by pressing the STBY button
