7 Installation
7.1 Location of the unit
The IS20 should be mounted with special regard to the
unit’s environmental protection, temperature range and
cable length. Refer page 75.
Avoid mounting the control unit(s) where it is easily
exposed to sunlight, as this may shorten the lifetime of
the display.
7.2 Mechanical installation
Panel mounting
The mounting surface must be flat and even to within 0.5
mm.
1. Drill the 4 mounting holes and make a panel cut-out
according to the drilling template included in the
package
2. Use the supplied 19 mm self tapping screws to secure
the control unit to the panel
3. Apply the front panel corners
Do not over-tighten the screws!
Installation | 47
