AP24
IS20 Graphic
12V SimNet supply
Red disk
T-joine
r
T-joiner
5,5 m
5,5 m
5 m
Compass
Non SimNet
SimNet backbone
SimNet drop cable
24
AP
MODE
MENU
AUTO
STBY
TURN
10
10
PWR
1
1
RF25 Rudder Feedback
AC12/AC42
SimNet network, small system
Installation | 51
