Simrad RS90S User Manual

| 103
Setup | RS90S User Manual
GPS REDIR
GPS redirection option set to output the GPS information to the
chart plotter, eliminating the need for an additional multiplexer.
1. Select MENU → AIS SETUP → GPS REDIR.
2. Scroll to YES or NO as required and press [OK].
• If you select YES, the string $RMC will be redirected to the chart
plotter once it is received.
¼ Note: The REDIR function will only redirect RMC and GLL messages
from NMEA 0183 input port to the AIS output port.
Setting up the CPA distance
Closest point of approach (CPA) is the calculated closest distance
between you and a target vessel based on the current speed and
course.
If the radio detects that a target vessel will come closer than the set
distance and within the set T/CPA time, the CPA alarm will sound a
two-tone alert.
1. Select MENU → AIS SETUP → CPA.
2. Use the ▲ and ▼ keys to raise or lower the CPA distance limit.
3. Press [OK].
¼ Note: The CPA distance is always in nautical miles.
DSC
MENU SELECT
GPS/DATA
RADIO SETUP
DSC SETUP
AIS SETUP
USA
16
Hi
DSC
AIS SETUP
AIS FUNC
AIS DISPLAY
GPS REDIR
BAUD RATE
Hi
USA
A
16
DSC
GPS REDIR
NO
YES
Hi
USA
A
16
DSC
MENU SELECT
GPS/DATA
RADIO SETUP
DSC SETUP
AIS SETUP
USA
16
Hi
DSC
AIS SETUP
BAUD RATE
GPS REDIR
AIS ALARM
CPA
Hi
USA
A
16
DSC
CPA
00.5NM
Hi
USA
A
16
