Installing a handset cable connector
Each wired handset cable includes a connector assembly that must
be installed in a bulkhead, dashboard or other suitable panel.
Socket body
Mounting
surface
Bezel
Drill 24 mm diameter hole
to clear socket body
Connector cover
