Installation | RS90S User Manual
Installing the transceiver
1. Hold the transceiver at the chosen location and mark the 4 hole
positions onto the mounting surface.
2. Drill the 4 holes where marked with a drill bit suited to the selected
mounting fasteners.
3. Attach the transceiver using the supplied self-tapping screws or
machine screws.
211.2 mm (8.31”)
195.1 mm (7.68”)
92.4 mm (3.64”)
195.7 mm (7.70”)
15.5 mm (0.61”)
65.0 mm (2.56”)
