Installing a wired handset cradle
This is the same as installing a wireless handset cradle with the
exception that no wiring is required. See “Installing a wireless
handset cradle” on page 74.
69.0 mm
(2.72”)
191.5 mm
(7.54”)
20.0 mm
(0.79”)
202.5 mm
(7.97”)
122.0 mm
(4.80”)
2 x 5.0 mm
(0.20”) holes
1 x 3.5 mm
(0.14”) hole
