8 |
Component overview | SRT LAN radar sensor S-band down-mast Service Manual
Component overview
Antenna and pedestal
A
D
F
GH
I
J
B
C
E
Description
A Antenna
B Pedestal
C Rotating joint
D Performance monitor arm
E Cover - motor side
F Cover - electronics side
G Coaxial cable
H SRT down-mast cable
I Safety switch
J Grounding terminal
SRT LAN down-mast transceiver
A
B
C
D
E
F
Description
A SRT down-mast cable
B Power cable
11
