communicateswithexternalperipherals,orhowlongtimethesystemusestosave

data.

4SetTxPowertoMaximum.

Result

TheSU90isnowtransmittingacousticpulses("pinging")intothewater.

Relatedtopics

Startingnormaloperation,page17

Adjustingtheradiusofthesearcharea

Someechoesareclose,othersarefurtheraway.Itisoftennecessarytoadjusttheradius

ofthesearcharea.OntheSU90,thisisreferredtoasrange.

Context

TheRangesettingdeneshow"far"youwishtheSU90todetectechoes.Inother

words,youspecifythehorizontalorverticaldistancefromthevesseltotheouteredge

ofthesearcharea.

Note

Therangevalueselectedandshownisbydefaultonlyusedbytheactiveview.

Eventhoughyoucanchoosealargerangevalue,thatdoesnotmeanthatyoucandetect

yourtargetsonthesamerange.Therangevalueonlydenestherangethatisshownin

theviews.Actualtargetdetectionwillalwaysdependontheoperationalenvironment,

suchaswatertemperature,salinity,interferenceandlayersinthewatercolumn.

Theselectedrangeisdividedintoidenticaldistances.Theseareshownasdottedcircles.

Theyarereferredtoasrangerings.

Tip

AnadjustablerangeringcanbeaddedtotheHorizontalandV erticalviews.Thisring

isreferredtoasthevariablerangering.

Procedure

1Clickintheviewyouwanttoactivate.

Theactiveviewisidentiedwithathickerborder.UnlessyouusetheApplytoall

function,allchangesyoumakewillonlybeappliedtothisview.
