Simrad SU90 Quick Start Guide

42
381292/C
Mainmenu
TheMainmenuislocatedatthetopofthemenustructure.Itoffersthemostcommon
functionsforefcientuseoftheSU90.Unlessyouhidetheentiremenusystem,the
Mainmenuisvisibleatalltimes,evenifyouclosethesecondarymenus.
Howtoopen
Bydefault,theMainmenuisopen.Itisplacedonthe
rightsideoftheSU90presentation.
Description
Themajorityofthechoicesprovidedbythismenuare
self-explanatory.Onlyspecicfunctionsofparticular
interestareexplainedwithbriefdescriptions.For
detailedinformationabouteachfunctionanddialog
box,refertotheSU90Referencemanualorthecontext
sensitiveon-linehelp.
Tip
Ifyoudonotneedtousethemenusystem,youcanhideit.Thisallowsmorespacefor
theSU90presentation.
UseMenuonthetopbartohideorshowthemenu.
Whenthemenusystemishidden,itappearstemporarilyontheleftorright
handsideofthescreenifyoumovethecursortothatposition.
BelowtheMainmenuyoundtheiconsforopening(andclosing)thesecondarymenus.
Selectanicontoopentherelevantmenu,andreselecttheicontoclosethemenu.
•UserSettings
TheUserSettingsdialogboxallowsyoutosavethecurrentusersettings(yourcurrent
selectionofoperationalparameters),andtoretrievefactoryorpreviouslysaveduser
settings.
•Range
TheRangefunctionallowsyoutospecifythemaximumdistancefromthetransducer
totheouteredgeofthesonarbeam.Therangevalueshownandselectedisbydefault
onlyappliedtothecurrentlyselectedview.
•Gain
ThepurposeoftheGainfunctionistoadjusttheecholevelintheSU90presentations.
ByadjustingthegainyoucancontrolhowmuchamplicationtheSU90applies
tothereceivedechoes.Thesettingisbydefaultonlyappliedtocurrentlyselected
echogram.Itisidentiedwithathickborder.
•Tilt
TheTiltfunctionallowsyoutocontroltheverticalangleofthesonarbeams.
SimradSU90QuickStartGuide
