Objectsmenu
TheObjectsmenuis-inspiteofitsnameandlocation-notamenuatall.This"menu"
opensasmallviewtomonitorandcontroltheobjectsyouhavedenedintheSU90
presentation.Eachobjectisidentiedwithavisualmarker.
Howtoopen
SelecttheObjectsicon.
TheiconislocatedundertheMainmenu.Selectthe
icononemoretimetoclosethemenu.
Description
Onceanechohasbeeprovidedwithamarkerinthe
SU90presentationitisregardedasanobject.The
Objectsmenuprovidesalistofallcurrentobjects.This
includesalltypesofobjectsincludingthoseclassied
astargets.
Inthiscontext,thephrasemarkerisusedto
identifyavisualsymbolplacedintheSU90
presentation.Byplacingamarkerontheechoit
isregardedasanobjectthatyoucanactupon.If
relevant,youcanfurtherclassifytheobjectasatarget.
ThephrasetargetisusedtoidentifyanechointheSU90presentationthatyouwish
toactupon.Theechomaybefromamaterialitem,ashallow,reeforrock,or
fromsh,shschoolsormammals.Youmustdecidewhichechoesthatshallbe
classiedastargets,andwetheryoushallstartpositionortargettracking.
Ifyouhaveplacedmarkersonseveralechoestomakethemobjects,youcanselectone
oftheseandgiveitprioritystatus.ThebearinglineintherelevantSU90viewswill
automaticallybelockedontheobjectwiththisprioritytoreectsitsbearing.Onlyone
singleobjectcanbegivenprioritystatus.Thepriorityisidentiedwitha"P".
Objectslist
OnceanechohasbeeprovidedwithamarkerintheSU90presentationitis
regardedasanobject.ThetableatthetopoftheObjectsmenushowsyouallthe
objectsthatarecurrentlyidentiedwithmarkers.Eachmarkedobjectislisted
withthefollowinginformation:
•ID:Thisistheuniqueidenticationofeachobjectmarker.
Eachmarkerisnumberedsequentially.
Objectswithallocatedmarkersareidentiedwithan"M"intheObjectsmenu.
Objectsthataresubjectedtotargettrackingareidentiedwitha"T".One
Menusystem
