Simrad SU90 Quick Start Guide

14
381292/C
OperatingPaneldescription
TheSU90OperatingPanelisthemostimportantdeviceforfastandefcientuser
interface.TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperation
oftheSU90.
ThecontrolsprovidedbytheOperatingPanelarearrangedinlogicalfunctionalgroups.
Thisoffersyouclearandeasyoperationwithfastaccesstokeyfunctionality.The
majorityoftheSU90functionscanbeaccessedusingthetrackballontheOperating
PanelandthemenusystemshownintheSU90presentation.TheOperatingPanelallows
youtoassigncertainfunctionstodedicatedbuttonsandswitches.
Tip
AUSBsocketisprovidedinthetopleftcorneroftheOperatingPanel.Usethissocketto
connectacomputerkeyboard,amouseoraUSBashdrive.
APower:PressthisbuttontoturntheSU90onandoff.
•BeforeyouturnontheSU90,makesurethatyouhavesufcientwaterdepthto
lowerthetransducer!
•YoumustneverturnontheSU90whentheshipisindrydock.Thetransducer
maybedamagedifittransmitsinopenair.
•YoumustneverturnofftheSU90bymeansoftheon/offswitchontheProcessor
Unit.YoumustALW AYSusetheOperatingPanel.
BSonarSelect:SincetheOperatingPanelusesEthernettocommunicatewiththe
ProcessorUnit,youcanuseonesinglepaneltocontrolmorethanonesonarsystem.
Tochangewhichsonartocontrol,pressSonarSelectontheOperatingPanel.If
youuseyourOperatingPaneltocontrolmorethantwosonars,pressSonarSelect
repeatedlytoselect.
CUserSettings:PressoneoftheUserSettingsbuttonstoapplyapredeneduser
setting.TochoosewhichfunctiontoapplyopentheOperatingPanelpage.Under
SimradSU90QuickStartGuide
