Simrad SU90 Quick Start Guide

50
381292/C
Activemenu
TheActivemenuoffersparametersrelatedtocurrentviewsanddatapresentationsshown
bytheSU90.
Howtoopen
SelecttheActiveicon.
TheiconislocatedundertheMainmenu.Selectthe
icononemoretimetoclosethemenu.
Description
Themajorityofthechoicesprovidedbythismenuare
self-explanatory.Onlyspecicfunctionsofparticular
interestareexplainedwithbriefdescriptions.For
detailedinformationabouteachfunctionanddialog
box,refertotheSU90Referencemanualorthecontext
sensitiveon-linehelp.
Thechoicesinthethismenudependsonwhichview
intheSU90presentationthatiscurrently"active".The
menumaythereforechangefromoneviewtoanother.
Thenameofthecurrentlyactiveviewisidentiedat
thetopofthemenu.Thescreencapturemaynotshow
youallthemenuchoices.
Note
Beforeyoucanchangethesettingsrelatedtoaview,youmustclickinsidetheviewto
activateit.Thechangesyoumakearebydefaultonlyvalidfortheactiveview.Severalof
thefunctionsofferApplytoAll.IfyouselectApplytoAllyoursettingisappliedtoallthe
viewsinthecurrentpresentationmode.
•TVG(TimeVariableGain)
Whenanacousticpulseissentthroughthewater,itwillgraduallyloseitsenergy.
Thegreaterthedistancebetweenthetransducerandthetarget(s),thegreatertheloss
ofenergy.TVG(TimeV ariableGain)compensatesforthelossofacousticenergy
duetogeometricspreadandabsorption.
•Ping-PingFilter
ThePing-PingFilteranalysesthehistoricalinformationfrompreviousconsecutive
pingsinordertoremoveunwantednoiseandfalseechoesfromtheSU90presentation.
SimradSU90QuickStartGuide
