Simrad SU90 Quick Start Guide

381292/C
7
Whenyouaredockingyourvessel
YoumustneversettheSU90tonormaloperationwhentheshipisindrydock.The
transducermaybedamagedifittransmitsinopenair.Topreventinadvertentuseofthe
SU90,pulloutthemainsplugontheProcessorUnitwheneveryourvesselisindrydock.
Additionalprecautionarymeasurersshouldbeconsidered.
Ifsomethingbreaksdown
Ifyoubelievethatsomethinghasbrokendown,contactyourlocaldealer.Alistofall
ourdealersisprovidedonourwebsite.
•https://www.simrad.com
Ifyouareunabletocontactadealer,observethesupportinformationinthispublication.
WhenyouwanttoturnofftheSU90
YoumustneverturnofftheSU90bymeansoftheon/offswitchontheProcessorUnit.
WhenyoudonotusetheSU90,turnitoffwiththePowerbuttonontheOperatingPanel.
IfthetransducerisloweredwhenyouturnofftheSU90,itisautomaticallyretractedto
itsupperposition.
Note
IfyouturnofftheSU90bymeansoftheon/offswitchontheProcessorUnityoumay
damagethesoftwareandtheinterfacesettingsusedtocommunicatewithexternal
devices.
Manualoperationofthehullunit
Intheeventofimproperoperation,thepowerfulelectricmotoronthehullunitmay
causeseriousdamagetotheequipmentand/orinjurytopersonnel.Therefore,before
you
startmanualoperation,readcarefullythroughtherelevantoperatingprocedures.
Note
Youmustfamiliarizeyourselfwiththecorrecthandlingmethodsandtherelevantsafety
requirements.
Rulesfortransducerhandling
Atransducermustalwaysbehandledasadelicateinstrument.Incorrectactionsmay
damagethetransducerbeyondrepair.Aphysicalblowtothetransducerfacemayeasily
damageoneormoreelements.Observethesetransducerhandlingrules:
•Donotactivatethetransducerwhenitisoutofthewater.
•Donothandlethetransducerroughlyandavoidimpacts.
•Donotexposethetransducertodirectsunlightorexcessiveheat.
•Donotdamagetheouterprotectiveskinofthetransducer.
SimradSU90
