Simrad SU90 - Operating Panel

14
409977/B
Transceiverboards(Fromright)SerialnumberRevision
6
7
8
9
10
11
12
Transceiverboard(Type):LPT32TransceiverBoard
Partnumber:425841
Ethernetswitch
Ethernetswitch(Makeandmodel)
1
Partnumber
2
SerialnumberRevision
Cisco2960L
454427
1
Theunitcontainsneithercircuitboardsnormodulesthatneedtobeidentiedseparately.IftheCisco
2960LEthernetswitchisnotusedwiththisdelivery,llininformationaboutthereplacementtypein
theemptyrow.
2
Thisisthepartnumberontheunitlabel.
OperatingPanel
TheOperatingPanelprovidedwiththeSU90deliverymustbeuniquelyidentied.
Make,model,partnumberandserialnumbermustberegistered.
SimradSU90HarbourAcceptanceTest
