Simrad SU90 Harbour Acceptance Test

409977/B
57
Secondaryprocedures
TheenduserandtechnicaldocumentationfortheSU90containsseveralproceduresthat
arealsoapplicableforthisHarbourAcceptanceTest.Theseproceduresarenot
partof
theHarbourAcceptanceTest.Theyareprovidedforreferencepurposesonly.Ifyou
scanacompletedHarbourAcceptanceTestforarchivingorreportingpurposes,itis
notnecessarytoincludetheseprocedures.
Topics
SettinguptheOperatingPanel(Mk2),page57
SettinguptheOperatingPanel(Mk2)
TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationofthe
SU90.Beforeitcanbeputtouse,theOperatingPanelmustbeconguredtopermit
EthernetcommunicationbetweenthepanelandtheProcessorUnit.
Prerequisites
TheOperatingPanelisinstalledasspeciedintheSU90Installationmanual.The
SU90ProcessorUnitisturnedon.
Thefollowingspecicitemsarerequiredforthistask.
•Computermouse
•Computerkeyboard
Neithertoolsnorinstrumentsarerequired.
Context
Whensupplied,theOperatingPanelissetupwiththefollowingcommunication
parameters:
•IPaddress:157.237.60.20
•Subnetmask:255.255.255.0
•Gateway:157.237.60.1
Secondaryprocedures
