•BaudRate:4800bit/s
•DataBits:8
•Parity:None
•StopBits:1
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectSensorInstallation.
aSelecttherelevantsensorintheInstalledSensorslist.
bMakesurethatthecorrectinstallationparametersareusedforthesensor.
4OntheleftsideoftheInstallationdialogbox,selectSensorConguration.
aSelecttherelevantsensorintheSensorlist.
bMakesurethatthecorrectparametersareusedforsensorconguration.
5ClosetheInstallationdialogboxwithoutmakinganychanges.
6Observethetopbar.
7Makesurethattheinformationfromthesensorisdisplayed.
Ifnecessary,enabletheread-outintheDisplayOptionsdialogbox.
8Ifpossible,useanotherinstrumenttoverifythattheinformationprovidedbythe
SU90iscorrect.
9Fillintheresulttables.
Result
DatagramPortBaudrateTalkerID
XOffsetYOffsetZOffset
Testingtheinterfaceswithperipheraldevices
