Singer S18 - Replacing the Light Bulb

72
Replacing the Light Bulb
WARNING
Turn the power off before replacing the light bulb.
The bulb could be HOT, wait until it has cooled down before
touching it.
To remove:
Remove the setscrew.
Remove the faceplate.
Swing the lamp socket to the left and pull out the bulb.
To replace:
Insert a new bulb into the opening of the socket.
Return the lamp socket to the original position.
Attach the faceplate with the setscrew.
1 Setscrew
2 Faceplate
3 Lamp socket
4 Light bulb
Replace a bulb with the same type, rated 12 V, 5 W.
1
2
4
3
