M300 Plus GNSS Receiver User Guide
4
sensor/barograph/inclinometer)
• 1 DB9 male port
- Standard RS232 protocol
• 1 Standard USB port,
- Connect with external storage card
• 1 RJ45 LAN Ethernet port (10/100M
Bit) supports
protocols HTTP, HTTPS, TCP/IP, UDP,
FTP, NTRIP
• 5 SMA male connectors
- 1 PPS output
- Event input
- Reserve for WLAN
- Frequency-marker oscillator input
connector
- GPRS antenna connector
• 1 TNC connectors
- GNSS Antenna connector
• 1 SIM Card Slot
- Nano-SIM card
Data Format
• Correction data I/O:
- RTCM 2.x, 3.x, RTCM3.2, MSM4,
MSM5, CMR (GPS only), CMR+(GPS only)
• Positioning data outputs:
- ASCII: NMEA-0183 GSV, RMC, HDT,
VHD, GGA, GSA, ZDA,
VTG, GST, PJK, PTNL
Antenna
• AT340 GNSS Geodetic Antenna
• AT350 GNSS Choke Ring Antenna
• AT500 GNSS Choke Ring Antenna
• AT600 GNSS Choke Ring Antenna
User Interface
• 4 LEDS in front panel
• ComNav M300 Plus Web Server
M
Specifications subject to change
without notice.
