FORE
WORD
• This manual is meant to prov
ide Customers with information on the machine and its
s
pecifications, and provides all the necessary operating and maintenance instructions in
order to ensure machine performance and longevity.
• This manual must be kept until the machine is disposed of. This manual should be accessible
to all maintenance and operating personnel.
CONTENTS
CHAP. 1 - RECEIVING THE MACHINE
page 4
1.1 -
PACKAGING
1.2 -
PACKAGING UPON DELIVERY
CHAP. 2 - INSTALLATION
page 6
2.1 UNPACKING
2.2 POSITIONING
2.3 -
ELECTRICAL CONNECTION
2.3.1 - Slicer with single-phase motor
2.3.2 - Slicer with 400 V. three-phase motor
2.3.3 - Slicer with 230 V. three-phase motor
2.3.4 - B
lade rotation direction
2.4 -
WIRING DIAGRAM
2.5 CONTROL PANEL
2.6 -
PRELIMINARY CHECK
CHAP. 3 - INFORMATION ON THE M
ACHINE
page 11
3.1 -
GENERAL SAFETY PRECAUTIONS
CHAP. 4 - GETTING FAMILIAR WITH THE SLICER
page 13
4.1 CONSTRUCTION FEATURE
S
4.2 -
SAFETY DEVICES INSTALLED ON THE MACHINE
4.2.1 - Mechanical safety
4.2.2 - E
lectrical safety
4.3 -
DESCRIPTION OF THE MACHINE
4.4 -
OVERALL DIMENSIONS, WEIGHT, FEATURES….
CHAP. 5 - USING THE MACHINE
page 18
5.1 - OPERATIONAL CHECK
5.1.1 - Using the controls
5.2 - LOADING AND CUTTING THE PRODUCT
5.3 -
SHARPENING THE BLADE
