Specifications
4-1
Chapter 4
Specifications
4.1 Specifications of Portable X-ray Unit
a) Charging input voltage: 50.4V
b) Input power: battery 44.4V
c) Max. output power: 3.2kW @ 100kV, 32mA，125kV, 25mA
d) Nominal power: 3.2kW @ 100kV, 32mA, 0.1s
e) Adjustable range of tube voltage: 40
-125kV, step value 1kV.
f) Adjustable range of tube current: 10mA, 12.5mA, 16mA, 20mA, 25mA, 32mA,
40mA, 50mA, 63mA, 80mA, ;
g) Stable Operating Frequency≥50kHz
h) Range of current time product: 0.4-200mAs, with the range of:
0.40, 0.50, 0.63, 0.80, 1.00, 1.25, 1.6, 2.0, 2.5, 3.2, 4.0, 5.0, 6.3, 8, 10, 12.5, 16,
20, 25, 32, 40, 50, 63, 80, 100, 125, 160, 200;
i) Small focus size: 0.6mm.
Big focus size: 1.8mm
j) Total filtration: 3mmAl (including the collimator), Fixed additional filtration:
1mmAl
k) Collimator: continuously adjustable, with the cross display for confirming the
position of the image receiver.
l) Indicator timing: not less than 30s.
m) Minimum X-ray radiation field: ≤ 5cm × 5cm @ 100cm SID.
n) Maximum X-ray radiation field: ≤ 35cm × 35cm @ 65cm SID.
o) Operating mode: continuous operation. If one exposure is done, the exposure
function will be locked by the device. Now the exposure is not available, while
other functions are still available for normal use. Wait for 60s before the device
unlocks the exposure function and performing the second exposure.
